D-2 A4ODE HYDRAULIC CIRCUIT "R" RANGE CIRCUIT [This page contains a complex hydraulic circuit diagram with various lines in red, blue, yellow, and black showing fluid flow paths. The diagram shows hydraulic components and their connections for the A4ODE transmission in reverse (R) range. Due to the technical nature and complexity of the hydraulic schematic, specific component labels and flow paths are shown but are difficult to transcribe in linear text format while maintaining accuracy.]
