D
/
Automatic Transmission Hydraulic Circuit
9 / 10
p.010 →
−
100%
+
D-9 4-AGZE 1-2 RANGE FIRST GEAR CIRCUIT Legend: Red Purple/Black Yellow/Blue Yellow/Green Battery Starting Charging Ignition Headlights Gauge A/C
