A/T INDICATOR (COMB. METER) W-B W-B R-B R-B R-B R-B Y BACK-UP LIGHTS (REAR COMB. LIGHT) BACK-UP LIGHT S/W (M/T) W-B W-B R-B RH Back-up Lights P-G B-O From "ING" Fuse (1-7) Y-B Y GR-G (1-6) (8-7) To TCCS ECU W-L (1-3) R-G (1-5) (8-11) L-Y From "RADIO No. 1" Fuse (6-6) SUPER MONITOR COMPUTER L-R From "CIG" Fuse (6-4) To Speed Sensor (2-1) B G-Y To Cruise Control Computer (5-1) From Igniter (1-7) (8-6) BR BR G From "TAIL" Fuse (5-4) W-B W-B Super Monitor 8 1 2 3 4 5 6 7 8 E8 E7 E6 E5 E4
