EMISSION CONTROL
SYSTEMS
Page
SYSTEM PURPOSE ............................................ EC-2
COMPONENT LAYOUT AND SCHEMATIC
DRAWING (7M-GE) ........................................ EC-3
COMPONENT LAYOUT AND SCHEMATIC
DRAWING (7M-GTE) ....................................... EC-4
POSITIVE CRANKCASE VENTILATION (PCV)
SYSTEM ..................................................... EC-5
FUEL EVAPORATIVE EMISSION CONTROL
(EVAP) SYSTEM ............................................ EC-6
DASH POT (DP) SYSTEM ................................... EC-8
EXHAUST GAS RECIRCULATION (EGR)
SYSTEM (7M-GE) ........................................... EC-12
EXHAUST GAS RECIRCULATION (EGR)
SYSTEM (7M-GTE) ......................................... EC-16
THREE-WAY CATALYST (TWC) SYSTEM .............. EC-20
NOTE: TROUBLESHOOTING
(See pages EM-4 to 6)
