PR/Propeller Shaft — Center Support Bearing and Flexible Couplings Inspection, page 10

(d) Separate the flexible coupling from the differential side.
HINT: If the flexible coupling cannot be easily separated by
hand, insert a screwdriver into the bolt hole of the flexible cou-
pling, as shown in the illustration then pry the coupling out.
NOTICE: Do not bring the screwdriver blade in direct
contact with the flexible coupling's rubber portion.
(e) Pull the yoke from the transmission.

(f) Install SST in the transmission to prevent oil leakage.
SST 09325–20010 (M/T)
       09325–40010 (A/T)

SST

CENTER SUPPORT BEARING AND
FLEXIBLE COUPLINGS INSPECTION

1. INSPECT CENTER SUPPORT BEARING
• Check for cracks in or damage to the cushion.
• Check if the bearing turns smoothly.
If the center support bearing is damaged, worn or does not
turn smoothly, replace it.

2. INSPECT FLEXIBLE COUPLINGS
• Check for cracks in or damage to rear flexible couplings.
If the flexible coupling is damaged, replace the propeller shaft
assembly.

3. INSPECT FLEXIBLE COUPLING CENTERING BUSHING
• Check for damage to the bushing.
If the bushing is damaged, replace the propeller shaft assem-
bly.
