EG–188
ENGINE – SFI SYSTEMS (2JZ–GE)
09843–18020 Diagnostic Check Wire
09990–01000 Engine Control Computer Check
Harness "A"
RECOMMENDED TOOLS
09082–00050 TOYOTA Electrical Tester Set
♦
09200–00010 Engine Adjust Kit ♦
09258–00030 Hose Plug Set ♦ Plug for vacuum hose, fuel
hose etc.
EQUIPMENT
Carburetor cleaner
Graduated cylinder Injector
Soft brush
Sound scope Injector
Tachometer
Torque wrench
Vacuum gauge
COOLANT
Item Capacity Classification
Engine coolant (w/ Heater) M/T 7.3 liters (7.7 US qts, 6.4 Imp. qts) Ethylene–glycol base
A/T 8.3 liters (8.8 US qts, 7.3 Imp. qts)
