WD/Wiring Diagrams — Electronically Controlled Transmission and A/T Indicator (For 2JZ–GTE), page 142

ELECTRONICALLY CONTROLLED TRANSMISSION AND A/T INDICATOR (FOR 2JZ–GTE)

E14
Y

P 2
A/T INDICATOR LIGHT SW
[PARK/NEUTRAL POSITION SW
(NEUTRAL START SW)]

P   R   N   D   2   L
7   8   10  9   2   3

GR  R-B  L   G-R  LG-R  G-B

R-B
LG-R
G-B
G-R

I17
E16
E16
I17

I14   I8

23  II1

Y

R-B
LG-R
G-B
G-R

GR

7 II1   36 II1   1 II1   18 II1   17 II1   27 II1

GR   R-B   L   G-R   LG-R   G-B

V10
VEHICLE SPEED SENSOR
(SPEED SENSOR
(FOR COMBINATION METER))

SPEED   MANU   O/D OFF   P   R   N   D   2   L

9 B   1 A   4 A   10 A   6 A   7 A   8 A   11 A

11 B   10 B   12 A   2 A   11 C   13 A

C10 B, C11 A, C12 C
COMBINATION METER

II1

I14

8 II1   2 II1

R
L-R

L-R

W-L
V-G

BR
W-B

W-L
V-G

V-G

I21

V-G

1 IF3

V-G

V-G

I11

V-G

W-B

A
J 1
JUNCTION
CONNECTOR
A

2
O 5
O/D MAIN
SW

4

W-B   BR   W-B

IE   IF   IH

144
