248
OVERALL ELECTRICAL WIRING DIAGRAM
SYSTEM INDEX
SYSTEMS LOCATION SYSTEMS LOCATION SYSTEMS LOCATION
ABS (Anti-Lock Brake System) 18-3 Headlight 6-3 (for Canada)
5-3 (for USA) Remote Control Mirror 11-4
ABS and Traction Control 19-3 Horn 9-4
Seat Heater (for Canada) 21-4
Auto Antenna 24-4 Ignition 2-4 (for 2JZ-GE)
2-2 (for 2JZ-GTE) Shift Lock 21-2
Back-Up Light 16-8 (for 2JZ-GE)
15-8 (for 2JZ-GTE) Illumination 8-3 SRS (Supplemental Restraint System) 13-3
Charging 1-4 Interior Light 10-3 Starting 1-2
Cigarette Lighter 21-1 Light Auto Turn Off 11-2 Stop Light 7-4
Clock 20-3 Power Seat 12-4 Taillight 7-2
Combination Meter 25-3 Power Source 1-26-1 Theft Deterrent and Door Lock Control 14-3
Cruise Control 17-3 Power Window 12-2 Turn Signal and Hazard Warning Light 9-2
Electric Tension Reducer 20-4 PPS (Progressive Power Steering) 20-3 Unlock and Seat Belt Warning 10-2
Electronically Controlled Transmission and A/T Indicator 16-3 (for 2JZ-GE)
15-3 (for 2JZ-GTE) Radiator Fan and Automatic Air Conditioning 26-3
Engine Control 4-3 (for 2JZ-GE)
3-3 (for 2JZ-GTE) Radio and Player 23-3 (w/ Stereo Power Amplifier)
24-2 (w/ Stereo Power Amplifier)
Fog Light 5-4 Remote Window Defogger and Mirror Heater 20-2
Front Wiper and Washer 22-4 Rear Wiper and Washer 22-2
