9. INSTALL POWER STEERING PUMP ONTO BRACKET
(a) Install the PS pump and stay.
(b) Install the PS pump pulley with the drive belt.
(c) Adjust the belt tension by prying until the specified belt tension is obtained. (See page MA-8)
(d) Tighten the idler pulley nut and adjusting bolt.
10. INSTALL INTAKE MANIFOLD
(a) Position a new gasket on the cylinder head.
(b) Install the intake manifold with eight bolts and two nuts. Torque the bolts and nuts.
Torque: 180 kg-cm (13 ft-lb, 18 N·m)
11. CONNECT EFI WIRE HARNESS TO ECU
12. INSTALL WATER OUTLET HOUSING
(a) Install the water outlet housing with two bolts.
(b) Connect the water by-pass hose and tighten the clamp.
13. INSTALL NO. 1 FUEL PIPE AND PULSATION DAMPER
(a) Finger tighten the pulsation damper and union bolt with new gaskets on the fuel pipe.
(b) Tighten the fuel pipe, being careful not to bend it.
14. INSTALL AIR INTAKE CHAMBER
(a) Position a new gasket on the intake manifold.
(b) Install the air chamber with five bolts and two nuts. Torque the bolts and nuts.
(c) Tighten the nut of the EGR valve connecting pipe.
15. CONNECT COLD START INJECTOR FUEL HOSE TO DELIV-ERY PIPE
Install the new gasket, fuel hose, another gasket and union bolt to the delivery pipe.
