DISASSEMBLY OF FRONT DOOR (See page BO-3) 1. REMOVE DOOR TRIM (a) Remove the courtesy light. (b) Remove the two bolts holding the door trim to the front door. (c) Insert a screwdriver between the retainers and the door panel to pry it loose. (d) Disconnect the wiring connector and remove the door trim. (e) Remove the upper door trim. (f) Remove the upper front garnish. 2. REMOVE SERVICE HOLE COVER 3. REMOVE REAR VIEW MIRROR (a) Remove the cover. (b) Disconnect the wiring connector. (c) Remove the three set screws and mirror. 4. REMOVE BELT MOULDING (a) Remove the top of the weatherstrip near the glass on both sides of the door. (b) Remove the two set screws, and pry loose the retainers with a scraper to remove the belt moulding. 5. REMOVE DOOR GLASS (a) Remove the upper stopper, trim support and inner stabilizer. (b) Raise the window up 20 — 40 mm (0.79 — 1.57 in.). (c) Remove the two guide set bolts.
