C/SST and SSM — SST (Special Service Tools) (Cont'd), page 7

SST (SPECIAL SERVICE TOOLS) (Cont'd)

Section
Classification
Part Name
Part No.
Illustration

09608-05110
Front Hub Inner &
Drive Pinion Front
Bearing Cup Replacer

09608-05120
Front Hub Outer
Bearing Cup Replacer

09610-20012
(Pitman Arm Puller)
A

09611-22012
(The Rod End Puller)
A

09612-24012
Steering Gear Housing
Overhaul Tool Set
B

09612-10021
Hexagon Wrench

09617-22030
(Steering Rack End
Wrench)

09617-24010
(Steering Rack Wrench)

09617-24020
Steering Pinion Bear-
ing Adjusting Screw
Lock Nut Wrench

09620-30010
Steering Gear Box
Replacer Set
B

09623-30010
Steering Worm
Bearing & Oil Seal
Replacer

09624-30010
Steering Sector Shaft
Oil Seal Replacer

09625-30010
Steering Main Shaft
Bearing Replacer

09631-00020
Handle

EM FI LI ST CH CL IE AT PR PE RA SR SF BZ B9
