← p.005
D
/
Automatic Transmission Hydraulic Circuit
, page 6
6 / 10
p.007 →
−
100%
+
Page text (OCR transcript)
D-6 70°C RANGE D GEAR CIRCUIT LOCK-UP OFF A-35E
