← p.006
D
/
Automatic Transmission Hydraulic Circuit
7 / 10
p.008 →
−
100%
+
A340E 22 RANGE FIRST GEAR CIRCUIT D-7 Line Pressure Torque Converter Pressure Coast Modulator Pressure Gov. Modulator Pressure
