BRAKE SYSTEM — Anti-lock Brake System (A.B.S.) BR-53
DIAGNOSTIC CODE
Code No. | Light Pattern | Diagnosis | Trouble Area
11 | ON OFF | Open circuit in solenoid relay | • Actuator (inside wire check)
| | | • Wire harness and connector of actuator and ECU
12 | ┌┐┌┐ | Short circuit in solenoid relay | • Wire harness and connector of actuator and ECU
| | | • Actuator (solenoid relay)
13 | ┌┐┌┐┌┐ | Open circuit in pump motor relay | • Actuator (solenoid wire check)
| | | • Wire harness and connector of pump motor and ECU
14 | ┌┐┌┐┌┐┌┐ | Short circuit in pump motor relay | • Wire harness and connector of pump motor and ECU
| | | • Actuator (pump motor relay)
21 | ┌ ┐ | Open or short circuit in RH position solenoid of front wheel | • Actuator (solenoid check)
| | | • Wire harness and connector of actuator and ECU
22 | ┌ ┐┌ ┐ | Open or short circuit in LH position solenoid of front wheel | • Actuator (solenoid check)
| | | • Wire harness and connector of actuator and ECU
23 | ┌ ┐┌ ┐┌ ┐ | Open or short circuit in RH position solenoid of rear wheel | • Actuator (solenoid check)
| | |
31 | ┌ ┐ | Right front wheel speed sensor signal malfunction | • Speed sensor
| | | • Sensor rotor
32 | ┌ ┐┌ ┐ | Left front wheel speed sensor signal malfunction | • Wire harness and connector of speed sensor
| | | • Sensor rotor
33 | ┌ ┐┌ ┐┌ ┐ | Rear wheel speed sensor signal malfunction | • Wire harness and connector of speed sensor
| | |
34 | ┌ ┐┌ ┐ | One circuit in front speed sensor | • Speed sensor
| | |
41 | ┌ ┐ | Low battery voltage (9.5 V or lower) | • Battery
| | | • Voltage regulator
42 | ┌ ┐┌ ┐ | Abnormally high battery voltage (17.2 V or higher) | • Pump motor duty and battery
| | | • Voltage regulator
51 | ┌ ┐ | Pump motor of actuator (block to open circuit in pump | • Pump motor duty and battery
| | motor circuit of actuator) | • Motor circuit of actuator
| | | • Kind of actuator error control circuit
Always on | ┐ | Malfunction in computer | • Computer
