EM-56
ENGINE MECHANICAL — Cylinder Head
(b) Apply seal packing to the cylinder head as shown in the illustration.
Seal packing: Part No. 08826-00080 or equivalent
(c) Install the No.1 and No.2 cylinder head covers.
Torque: 25 kg·cm (2 ft·lbf, 2 N·m)
(d) Install the heater hose clamp.
(e) Install the accelerator link.
5. INSTALL WATER OUTLET HOUSING
(a) Install a new gasket and water outlet housing with the bolt and two nuts.
(b) Connect the No.6 water by-pass hose.
(c) (7M-GE)
Install unions with No.4 water by-pass hose to the water outlet housing with new gaskets and union bolts.
6. INSTALL EXHAUST MANIFOLD
(a) Face a new exhaust gasket so the protrusion is facing the rear and install on the cylinder head.
EM2907
EM5231
EM5926
EM5927
EM6264
Protrusion
