PSEAT/Power Seat — P11 Power Seat Control Sw (For Driver's Seat), page 2

SERVICE HINTS
P11 POWER SEAT CONTROL SW (FOR DRIVER'S SEAT)
2– GROUND: ALWAYS APPROX. 12 VOLTS
1– GROUND: ALWAYS CONTINUOUS

: PARTS LOCATION
CODE SEE PAGE CODE SEE PAGE CODE SEE PAGE
P11 31 P12 31

: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODE SEE PAGE JUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1H 20 COWL WIRE AND J/B NO.1 (LEFT KICK PANEL)

: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODE SEE PAGE JOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
iC2 36 FLOOR NO. 2 WIRE AND COWL WIRE (LEFT KICK PANEL)
B01 42 FLOOR NO. 2 WIRE AND SEAT WIRE (UNDER THE FRONT LH SEAT)

: GROUND POINTS
CODE SEE PAGE GROUND POINTS LOCATION
BI 40 LEFT QUARTER PILLAR

P11 P12
[Diagram showing two connector diagrams: P11 with 4 pins numbered 1, 2, 3, 4 and P12 with 2 pins numbered 1, 2]
