SRS/Supplemental Restraint System — Service Specifications Service Data, page 102

RS–102
SUPPLEMENTAL RESTRAINT SYSTEM – SERVICE SPECIFICATIONS

SERVICE SPECIFICATIONS
SERVICE DATA

FRONT AIRBAG SENSOR
⊕S – ⊕A	755–885 Ω
⊕S – ⊖S	1 MΩ or Higher
⊖S – ⊖A	Less than 1 Ω

TORQUE SPECIFICATIONS

Part tightened	N·m	kgf·cm	ft·lbf
Steering wheel	35	360	26
Steering wheel pad	7.1	72	62 in.·lbf
Front passenger airbag assembly x Instrument panel reinforcement	21	210	15
Front passenger airbag assembly x Instrument panel	8.8	90	78 in.·lbf
Front airbag sensor	29	300	22
Airbag sensor assembly	21	210	15
