WD/Wiring Diagrams — Service Hints, page 188

SERVICE HINTS
P11 POWER SEAT CONTROL SW (FOR DRIVER'S SEAT)
2– GROUND: ALWAYS APPROX. 12 VOLTS
1– GROUND: ALWAYS CONTINUOUS

: PARTS LOCATION
CODE    SEE PAGE    CODE    SEE PAGE    CODE    SEE PAGE
P11     31          P12     31

: JUNCTION BLOCK AND WIRE HARNESS CONNECTOR
CODE    SEE PAGE    JUNCTION BLOCK AND WIRE HARNESS (CONNECTOR LOCATION)
1H      20          COWL WIRE AND J/B NO.1 (LEFT KICK PANEL)

: CONNECTOR JOINING WIRE HARNESS AND WIRE HARNESS
CODE    SEE PAGE    JOINING WIRE HARNESS AND WIRE HARNESS (CONNECTOR LOCATION)
IC2     36          FLOOR NO. 2 WIRE AND COWL WIRE (LEFT KICK PANEL)
BQ1     42          FLOOR NO. 2 WIRE AND SEAT WIRE (UNDER THE FRONT LH SEAT)

: GROUND POINTS
CODE    SEE PAGE    GROUND POINTS LOCATION
BI      40          LEFT QUARTER PILLAR

P11                 P12
1  2
3  4

1  2

191
