APPENDIX–REPORTING OF WIRE HARNESS PROBLEM

WIRE HARNESS PROBLEM:
page 2/3
Please fill in the required information in the brackets and check the appropriate box.

E.W.D Page (          )
*CONNECTOR NO.A (     )          CONNECTOR NO.B (     )
Problem occurred between    PIN NO. (     )          and    PIN NO. (     )
WIRE COLOR (     )                    WIRE COLOR (     )

* The problem indicated below occurred at a distance
of (     mm) from connector A (     )

SHORT          OPEN

POOR CONTACT OF
RING TYPE TERMINAL

PINCHED                    CUT WIRE                    EARTH TERMINAL
INTERFERENCE/ABRATION    SPLICE POINT               POWER SOURCE TERMINAL
MOISTURE                   OTHRES;                     BATTERY
CORROSION, RUST                                         STARTER
OTHERS;                                                 ALTERNATOR

Name of the other part which       INSULATION:
causef the short/open of wire      YES          NO
                                   CONDUIT TUBE             LOOSE SET BOLT
                                   VINYL TUBE               CORROSION, RUST
BODY    Name                       VINYL TAPE               OTHERS (     )
PART                               VINYL SHEET
OTHERS                             OTHERS (     )

Note:    If possible, attach an illustration or photo to show the part causing the short or open, and
the position of the wire and the other part.
This will help to make the cause of the problem clear and help us to take prompt action.

Box B
If you checked the "Others" box in the "Symptom" section on page 3-1, please describe:
Symptom:
Condition:
Related Wire Harness or Connector;
Name or Part NO.:
Location:
