AUTOMATIC TRANSMISSION — Removal and Installation of Transmission REMOVAL AND INSTALLATION OF TRANSMISSION Remove and install the parts as shown. Exhaust Pipe Bracket Exhaust Front Pipe Rubber Hanger SST 09305-40010 Manual Shifter Propeller Shaft Spacer 770 kgf·cm (56 ft·lbf, 75 N·m) 520 kgf·cm (38 ft·lbf, 51 N·m) Transmission Box Rear Support Member Rear Mounting 770 kgf·cm (56 ft·lbf, 75 N·m) 640 kgf·cm (46 ft·lbf, 63 N·m) Oil Cooler Pipe 250 kgf·cm (18 ft·lbf, 25 N·m) 250 kgf·cm (18 ft·lbf, 25 N·m) Torque Converter Clutch Wiring Connector Fuel Tank Throttle Cable 630 kgf·cm (46 ft·lbf, 62 N·m) Overrunner Cover Engine Under Cover Stiffener Plate Starter 430 kgf·cm (31 ft·lbf, 42 N·m) Specified torque 4 screws, 11.3 cm (15 in.·lbf, 1.7 N·m) Non-reusable part ATM073
