WD/Wiring Diagrams — Electronically Controlled Transmission and A/T Indicator (for 2JZ-GTE), page 261

15 SUPRA (Cont'd)

Electronically Controlled Transmission and A/T Indicator
(for 2JZ–GTE)

Back–Up Light (for 2JZ–GTE)

5

6

7

8

B-Y

Y

Y

Y

(M/T)

(A/T)

19A
GAUGE

P2
BACK-UP
LIGHT SW

G-R
R-B
LG-R
G-B

To Cruise Control
ECU417-25

G-R

(M/T)

(A/T)

3

2

1

6

5

4

7

8

9

GR

R-B

L

G-R

LG-R

G-B

R-B
(M/T)

R-B
(A/T)

R-B
(A/T)

R-B

R-B

GR

L

G-R

LG-R

G-B

38

19

18

17

16

E1
12

R-B

To Data Link
Connector 2
(TDCL25-8...

R-B
LG-R
G-B

V-G

V-G

V-G

V-G

W-L

G-Y

W-B

O5
O.D MAIN SW

1
2
3
4

MANUAL
NORMAL

E8 ELECTRONICALLY CONTROLLED
TRANSMISSION PATTERN
SELECT SW

V-G
W-B
V-G
W-B

Y

Y

V-G

W-L

W-B

W-B

MR5

1
2
3
4
5
6
7
8
9
10
11
12
13

O'D OFF
MANU

P
R
N
D
L

C11
A/T INDICATOR LIGHT
(COMBINATION METER)

See Combination Meter
<25-8>

JUNCTION
CONNECTOR

A
B
C

W-B

W-B

W-B

W-B

Right kick panel

Left kick panel

R10
RH

R9
LH

BACK-UP LIGHT
[REAR COMB. LIGHT]

Left quarter pillar

Rear body
panel center

W-B

W-B

W-B

W-B
