C–9 TABLE OF HOUSING CROSS SECTION Type ○ : Position of the lance ↕ : Direction of lock released ➤ : Direction of the special tool inserted Male Female FOG– LP (Double Lock Type) [Housing Lance] FTC (Double Lock Type) [Housing Lance] HEAD LAMP Waterproof Type [Housing Lance] HB3 HB4 [Housing Lance] Wire Harness Repair Manual (RM1022E) 72
