C–10 TABLE OF HOUSING CROSS SECTION Type ○ : Position of the lance ↕ : Direction of lock released ↑ : Direction of the special tool inserted Male Female LAC [Housing Lance] [Housing Lance] MFPC [Housing Lance] MIC [Terminal Lance] PULSE LOCK [Housing Lance] Wire Harness Repair Manual (RM1022E) 73
