The procedures are presented in a step–by–step format:
• The illustration shows what to do and where to do it.
• The task heading tells what to do.
• The detailed text tells how to perform the task and gives other information such as specifications and warnings.
Example:
Task heading: what to do
21. CHECK PISTON STROKE OF OVERDRIVE BRAKE
(a) Place SST and a dial indicator onto the overdrive brake piston as shown in the illustration.
SST 09350-30020 (09350-06120)
Set part No. Component part No.
Detailed text: how to do task
(b) Measure the stroke applying and releasing the compressed air (392 — 785 kPa, 4 — 8 kgf/cm² or 57 — 114 psi) as shown in the illustration.
Piston stroke: 1.40 — 1.70 mm (0.0551 — 0.0669 in.)
Specification
Illustration:
what to do and where
This format provides the experienced technician with a FAST TRACK to the information needed. The upper case task heading can be read at a glance when necessary, and the text below it provides detailed information. Important specifications and warnings always stand out in bold type.
REFERENCES
References have been kept to a minimum. However, when they are required you are given the page to refer to.
SPECIFICATIONS
Specifications are presented in bold type throughout the text where needed. You never have to leave the procedure to look up your specifications. They are also found at the end of each section, for quick reference.
