248 OVERALL ELECTRICAL WIRING DIAGRAM SYSTEM INDEX SYSTEMS LOCATION SYSTEMS LOCATION SYSTEMS LOCATION ABS (Anti-Lock Brake System) 18-3 Headlight 6-3 (for Canada) 5-3 (for USA) Remote Control Mirror 11-4 ABS and Traction Control 19-3 Horn 9-4 Seat Heater (for Canada) 21-4 Auto Antenna 24-4 Ignition 2-4 (for 2JZ-GE) 2-2 (for 2JZ-GTE) Shift Lock 21-2 Back-Up Light 16-8 (for 2JZ-GE) 15-8 (for 2JZ-GTE) Illumination 8-3 SRS (Supplemental Restraint System) 13-3 Charging 1-4 Interior Light 10-3 Starting 1-2 Cigarette Lighter 21-1 Light Auto Turn Off 11-2 Stop Light 7-4 Clock 20-3 Power Seat 12-4 Taillight 7-2 Combination Meter 25-3 Power Source 1-26-1 Theft Deterrent and Door Lock Control 14-3 Cruise Control 17-3 Power Window 12-2 Turn Signal and Hazard Warning Light 9-2 Electric Tension Reducer 20-4 PPS (Progressive Power Steering) 20-3 Unlock and Seat Belt Warning 10-2 Electronically Controlled Transmission and A/T Indicator 16-3 (for 2JZ-GE) 15-3 (for 2JZ-GTE) Radiator Fan and Automatic Air Conditioning 26-3 Engine Control 4-3 (for 2JZ-GE) 3-3 (for 2JZ-GTE) Radio and Player 23-3 (w/ Stereo Power Amplifier) 24-2 (w/ Stereo Power Amplifier) Fog Light 5-4 Remote Window Defogger and Mirror Heater 20-2 Front Wiper and Washer 22-4 Rear Wiper and Washer 22-2
